ADSCivil Intersection - Junction design
The optimal solution for at-grade junction design
01 — Junction design software
In urban transport infrastructure design, at-grade junctions matter a great deal — yet they often receive too little attention, with serious consequences during construction and operation. Design faults such as storage lanes that are too short, unsuitable right-turn lanes, or inaccurately located low points can cause congestion and expensive remedial work. To address this, ADSCivil Intersection was developed as a comprehensive solution that raises design quality, ensures accuracy and optimises both construction and operation.
02 — Overview
Software dedicated to junction design
ADSCivil Intersection is the first "Made in Vietnam" tool for at-grade junction design within the ADSCivil suite.
Keeping data consistent
The software inherits and synchronises data from routes already designed in ADSCivil Road, keeping junction design accurate and consistent.
Flexible and easy to use
ADSCivil Intersection offers a friendly, approachable and flexible interface that makes it easy for traffic engineers to design complex junctions.
Automatic export of quantities and coordinates
The software automatically produces preliminary quantity schedules and tables of junction control point coordinates for construction and project management.
A wide range of applications
As well as standard junctions, the software handles complex roundabouts and can synchronise the design model into ADSCivil VPV for 3D model review.
03 — Benefits
- Higher design quality: the software helps avoid common faults such as missing storage lanes, unsuitable lane lengths and badly placed low points, raising the quality of junction design.
- Time and cost savings: by copying design parameters automatically, ADSCivil Intersection cuts working time and reduces the cost of design faults and unnecessary changes.
- Consistency and accuracy: inheriting design data directly from ADSCivil Road keeps the design consistent and accurate, reducing errors during delivery and construction.
- Optimised construction: the software produces detailed quantity schedules and control point coordinates, making construction faster and more accurate and reducing incidents on site.
- Better management and control: synchronising the design model into ADSCivil VPV and integrating with visualisation software such as Twinmotion makes the whole construction and operation process easier to manage and control.
04 — Features
Diverge and merge lane design
- Supports the design of left- and right-turn lanes.
- Optimises traffic at junctions and avoids congestion.
- Improves vehicle flow through the junction.
Copying design parameters
- Cuts out repetitive work when designing identical junctions.
- Saves design time on projects with many similar junctions.
- Reapply design parameters to different junctions without manual editing.
Flexible junction design
- Each junction corner is treated as an independent alignment, making cross falls easy to design and control.
- Control the transition of kerb levels within each arm to keep the design stable.
- Calculate detailed quantities to support construction.
Automatic junction contour export
- Automatically export preliminary quantity schedules and junction control point coordinates.
- Supports fast, accurate setting out on site.
- Reduces errors during delivery.
3D model integration
- Synchronise the design model into ADSCivil VPV to review the whole junction.
- Export 3D models and visualisations through Twinmotion or other rendering software.
- Strengthens project management and simulation during design and construction.
Starter
Try it before you decide
Try ADSCivil Intersection — advanced junction design software that helps you overcome the challenges of designing at-grade junctions and roundabouts!
